Professional Pro-AVIT stock

JD Media ZA-1120A Amplifier

Name: JD Media ZA-1120A Amplifier
Brand: Pro-AVIT
SKU: NORM05397
Availability: InStock

SKU: NORM05397 ·Brand: Pro-AVIT

£0.00 GBP

Sale Sold out

Approx. £0.00 ex VAT

1 7

Product summary

Packed and ready for dispatch.

Pro-AVIT stock supplied as described. Check the condition, testing status, model, part number and photos before ordering.

Item: JD Media ZA-1120A Amplifier

30-Day Returns

Fast UK Dispatch

JD Media ZA-1120A Amplifier

£0.00 GBP

Sale Sold out

Taxes included. Shipping calculated at checkout.

This item has been fully tested and is in good working condition. Cosmetically this unit has some minor marks and scratches but is in overall good condition.

Includes FM/AM module.

INPUT SENSITIVITY/IMPEDANCE

MIC/LINE1-3 : -50dBu(2.45mV) 5kΩ BAL

: -10dBu(245mV) 5kΩ BAL

LINE 4–5 : -10dBu(245mV) 15kΩ UNBAL

TEL PAGING : -10dBu(245mV) 5kΩ BAL

PACK UNIT : -10dBu(245mV) 10kΩ UNBAL

REC OUT : 0dBu(775mV) 3kΩ UNBAL

PRE OUT : 0dBu(775mV) 10kΩ UNBAL

AMP IN : 0dBu(775mV) 10kΩ UNBAL

RATED OUTPUT

ZA-1120A : 120W(RMS)

ZA-1240A : 240W(RMS)

OUTPUT IMPEDANCE/ATT. STEP (OPTION)

LOW IMP : 4Ω

EUROPE : 100V, 70V, 50V, 25V, 12.5V, 8.9V

AMERICA : 70V, 50V, 25V, 12.5V, 8.9V, 6V

FREQUENCY RESPONSE (LINE SIGNAL)

LESS THAN 3dB(55Hz ~ 16kHz)

SIGNAL TO NOISE RATIO

LINE : MORE THAN 80dB(“A” WEIGHT)

MIC : MORE THAN 70dB(“A” WEIGHT)

T.H.D

LESS THAN 1%(1kHz)

POWER CONSUMPTION

ZA-1120A : 350W

1/8 POWER CURRENT DRAW 120V/230V

ZA-1120A : 1.6A / 0.8A

1/3 POWER CURRENT DRAW 120V/230V

ZA-1120A : 2.4A / 1.2A

RATED POWER CURRENT DRAW 120V/230V

ZA-1120A : 3.6A / 1.8A

View full details
